Christmas Show - my drum & mic setup for you drummers out there

Jeff Babcock

Senior
Jan 11, 2011
1,045
32
48
Ontario, Canada
jeffbabcock.org
I did a Christmas gig this past weekend with some great musicians and had a lot of fun playing to a packed house. I played drums for the show, but also provided PA and lighting rigs for the event.

For some reason I always forget to take photos of gigs, so I just thought I would post a couple pics of yours truly with my personal kit and the mic setup used (yes, I play southpaw). Photos taken with my friend's Nikon D3.

The configuration shown in the photos is:
22" kick
14" snare
10" popcorn snare
8", 10", 12", 14", 16" toms (12" as an aux tom)
Cymbals are a mix of Zildjian, Paiste, Sabian, and Turkish

Mics used:

Kick - Audix D6. Note that there is no hole in the front head of the bass drum. The front head has multiple smaller holes around the perimeter, so the effect is similar to a ported head. The D6 is mounted on a Kelly SHU internal mounting system, and is arranged so that you simply plug an XLR into a tail on the kick and go. While the SHU makes no sense for a regional provider, musicians wishing to implement them on their personal kits won't be disappointed.

Snare 1 - SM57 - 'nuff said, it works. Sometimes I use a PR20.

Snare 2 - Heil PR20 - works great

Hats - MXL 606 - it's cheap and it works fine for the tiny amount of hat needed in the mix

Toms - Beyerdynamic Opus 88. These are wonderful drum mics, the mounting system works very well and they have a fairly tight pattern which helps to minimize bleed.

Overheads - Neumann KM184. This is a matched pair, and they were implemented in the X/Y (coincident pair) arrangement. Most of the experienced users here are familiar with this, but for those who aren't, X/Y helps to minimize time of arrival / phase issues. I do not always use X/Y, it depends on the circumstances, there are lots of other useful options (I'm becoming a Recorderman technique fan, and use spaced pair often as well)

In many circumstances I mic the bottom snare head as well as the ride cymbal, but in this particular case didn't feel that it was necessary.

Monitoring for the gig was via a mix of IEMs and Wedges (10 mixes). The Sennheiser G2 rig and antenna distro I bought from Jim Bowersox has gotten a lot of use and been a reliable workhorse. For those using an IEM rig without a good external antenna system, you're missing out in terms of reliability.

This gig was recorded and filmed which will make for some nice memories.

As this is only partially audio related, feel free to move to the basement if it makes more sense there.

Cheers
Jeff


Attachments

  • 20111210_celebrate_christmas_187.jpg
    186.3 KB · Views: 0
  • 20111210_celebrate_christmas_314.jpg
    244.7 KB · Views: 0
Last edited:
Re: Christmas Show - my drum & mic setup for you drummers out there

As a fellow drummer / sound guy, thanks for the pics. Very nice kit, always a bit strange seeing lefty set up. I occasionally do some minor league recording so I am also partial to the XY overhead set up. Dont see that too often in live applications but I mic the same way on stage!!

Re: Christmas Show - my drum & mic setup for you drummers out there

My overhead technique strictly depends on the monitor level of the band and the type of show. XY for the controlled stage sound, but I have a guy who likes his monitors loud and when he on the stage I have to go split pair closer (lower) to the cymbals.

Re: Christmas Show - my drum & mic setup for you drummers out there

Thanks for the pics! Another drummer here too. Oddly enough, another lefty but play with the kit set up for a righty. Spec's on your drumset?

Re: Christmas Show - my drum & mic setup for you drummers out there

Seasonal employment for drummer boys.... who'd a thunk it? And you really need to send me the KM184s, I've been very good this year!

Re: Christmas Show - my drum & mic setup for you drummers out there

you really need to send me the KM184s, I've been very good this year!

Tim, I'm not sure I believe you. Santa said he was going to give you a lump of coal but I felt bad for you and convinced him otherwise....

I hate to spoil the surprise..... but seeing this in advance will help to inspire you to dream over the holidays.....
